楼主写一个html，很容易把下面代码嵌入到applet，可以google一下实现，

还有copy自己不知道算不算复制。。。-_-!

--------------------------------------------------------------------

楼主给你一个我的，直接保存成pb.java编译运行，就是你要的画图功能，可以参考一下

____________________________________________________________________

import java.applet.*;

import java.awt.*;

import java.awt.event.*;

import java.util.*;

import javax.swing.*;

import java.awt.geom.*;

import java.io.*;

class Point implements Serializable

{

int x,y;

Color col;

int tool;

int boarder;

Point(int x, int y, Color col, int tool, int boarder)

{

this.x = x;

this.y = y;

this.col = col;

this.tool = tool;

this.boarder = boarder;

}

class paintboard extends Frame implements ActionListener,MouseMotionListener,MouseListener,ItemListener

{

int x = -1, y = -1;

int con = 1;//画笔大小

int Econ = 5;//橡皮大小

int toolFlag = 0;//toolFlag:工具标记

//toolFlag工具对应表：

//（0--画笔）；（1--橡皮）；（2--清除）；

//（3--直线）；（4--圆）；（5--矩形）；

Color c = new Color(0,0,0); //画笔颜色

BasicStroke size = new BasicStroke(con,BasicStroke.CAP_BUTT,BasicStroke.JOIN_BEVEL);//画笔粗细

Point cutflag = new Point(-1, -1, c, 6, con);//截断标志

Vector paintInfo = null;//点信息向量组

int n = 1;

FileInputStream picIn = null;

FileOutputStream picOut = null;

ObjectInputStream VIn = null;

ObjectOutputStream VOut = null;

// *工具面板--画笔，直线，圆，矩形，多边形,橡皮，清除*/

Panel toolPanel;

Button eraser, drLine,drCircle,drRect;

Button clear ,pen;

Choice ColChoice,SizeChoice,EraserChoice;

Button colchooser;

Label 颜色,大小B,大小E;

//保存功能

Button openPic,savePic;

FileDialog openPicture,savePicture;

paintboard(String s)

{

super(s);

addMouseMotionListener(this);

addMouseListener(this);

paintInfo = new Vector();

/*各工具按钮及选择项*/

//颜色选择

ColChoice = new Choice();

ColChoice.add("black");

ColChoice.add("red");

ColChoice.add("blue");

ColChoice.add("green");

ColChoice.addItemListener(this);

//画笔大小选择

SizeChoice = new Choice();

SizeChoice.add("1");

SizeChoice.add("3");

SizeChoice.add("5");

SizeChoice.add("7");

SizeChoice.add("9");

SizeChoice.addItemListener(this);

//橡皮大小选择

EraserChoice = new Choice();

EraserChoice.add("5");

EraserChoice.add("9");

EraserChoice.add("13");

EraserChoice.add("17");

EraserChoice.addItemListener(this);

////////////////////////////////////////////////////

toolPanel = new Panel();

clear = new Button("清除");

eraser = new Button("橡皮");

pen = new Button("画笔");

drLine = new Button("画直线");

drCircle = new Button("画圆形");

drRect = new Button("画矩形");

openPic = new Button("打开图画");

savePic = new Button("保存图画");

colchooser = new Button("显示调色板");

//各组件事件监听

clear.addActionListener(this);

eraser.addActionListener(this);

pen.addActionListener(this);

drLine.addActionListener(this);

drCircle.addActionListener(this);

drRect.addActionListener(this);

openPic.addActionListener(this);

savePic.addActionListener(this);

colchooser.addActionListener(this);

颜色 = new Label("画笔颜色",Label.CENTER);

大小B = new Label("画笔大小",Label.CENTER);

大小E = new Label("橡皮大小",Label.CENTER);

//面板添加组件

toolPanel.add(openPic);

toolPanel.add(savePic);

toolPanel.add(pen);

toolPanel.add(drLine);

toolPanel.add(drCircle);

toolPanel.add(drRect);

toolPanel.add(颜色); toolPanel.add(ColChoice);

toolPanel.add(大小B); toolPanel.add(SizeChoice);

toolPanel.add(colchooser);

toolPanel.add(eraser);

toolPanel.add(大小E); toolPanel.add(EraserChoice);

toolPanel.add(clear);

//工具面板到APPLET面板

add(toolPanel,BorderLayout.NORTH);

setBounds(60,60,900,600); setVisible(true);

validate();

//dialog for save and load

openPicture = new FileDialog(this,"打开图画",FileDialog.LOAD);

openPicture.setVisible(false);

savePicture = new FileDialog(this,"保存图画",FileDialog.SAVE);

savePicture.setVisible(false);

openPicture.addWindowListener(new WindowAdapter()

{

public void windowClosing(WindowEvent e)

{ openPicture.setVisible(false); }

});

savePicture.addWindowListener(new WindowAdapter()

{

public void windowClosing(WindowEvent e)

{ savePicture.setVisible(false); }

});

addWindowListener(new WindowAdapter()

{

public void windowClosing(WindowEvent e)

{ System.exit(0);}

});

}

public void paint(Graphics g)

{

Graphics2D g2d = (Graphics2D)g;

Point p1,p2;

n = paintInfo.size();

if(toolFlag==2)

g.clearRect(0,0,getSize().width,getSize().height);//清除

for(int i=0; i<n ;i++){

p1 = (Point)paintInfo.elementAt(i);

p2 = (Point)paintInfo.elementAt(i+1);

size = new BasicStroke(p1.boarder,BasicStroke.CAP_BUTT,BasicStroke.JOIN_BEVEL);

g2d.setColor(p1.col);

g2d.setStroke(size);

if(p1.tool==p2.tool)

{

switch(p1.tool)

{

case 0://画笔

Line2D line1 = new Line2D.Double(p1.x, p1.y, p2.x, p2.y);

g2d.draw(line1);

break;

case 1://橡皮

g.clearRect(p1.x, p1.y, p1.boarder, p1.boarder);

break;

case 3://画直线

Line2D line2 = new Line2D.Double(p1.x, p1.y, p2.x, p2.y);

g2d.draw(line2);

break;

case 4://画圆

Ellipse2D ellipse = new Ellipse2D.Double(p1.x, p1.y, Math.abs(p2.x-p1.x) , Math.abs(p2.y-p1.y));

g2d.draw(ellipse);

break;

case 5://画矩形

Rectangle2D rect = new Rectangle2D.Double(p1.x, p1.y, Math.abs(p2.x-p1.x) , Math.abs(p2.y-p1.y));

g2d.draw(rect);

break;

case 6://截断，跳过

i=i+1;

break;

default :

}//end switch

}//end if

}//end for

}

public void itemStateChanged(ItemEvent e)

{

if(e.getSource()==ColChoice)//预选颜色

{

String name = ColChoice.getSelectedItem();

if(name=="black")

{c = new Color(0,0,0); }

else if(name=="red")

{c = new Color(255,0,0);}

else if(name=="green")

{c = new Color(0,255,0);}

else if(name=="blue")

{c = new Color(0,0,255);}

}

else if(e.getSource()==SizeChoice)//画笔大小

{

String selected = SizeChoice.getSelectedItem();

if(selected=="1")

{

con = 1;
