stm32最小系统rtc电路有什么用
展开全部 struct tm是直观意义上的时间表示方法: struct tm { int tm_sec; /* 秒–取值区间为[0,59] */ int tm_min; /* 分 - 取值区间为[0,59] */ int tm_hour; /* 时 - 取值区间为[0,23] */ int tm_mday; /* 一个月中的日期 - 取值区间为[1,31] */ int tm_mon; /* 月份(从一月开始,0代表一月) - 取值区间为[0,11] */ int tm_year; /* 年份,其值从1900开始 */ int tm_wday; /* 星期–取值区间为[0,6],其中0代表星期天,1代表星期一,以此类推 */ int tm_yday; /* 从每年的1月1日开始的天数–取值区间为[0,365],其中0代表1月1日,1代表1月2日,以此类推 */ int tm_isdst; /* 夏令时标识符,实行夏令时的时候,tm_isdst为正。
不实行夏令时的进候,tm_isdst为0;不了解情况时,tm_isdst()为负。
*/ long int tm_gmtoff; /*指定了日期变更线东面时区中UTC东部时区正秒数或UTC西部时区的负秒数*/ const char *tm_zone; /*当前时区的名字(与环境变量TZ有关)*/ }; 程序举例 #include #include int main(void) { struct tm *ptr; time_t lt; lt =time(NULL); ptr=localtime(<); printf("second:%d\n",ptr->tm_sec); printf("minute:%d\n",ptr->tm_min); printf("hour:%d\n",ptr->tm_hour); printf("mday:%d\n",ptr->tm_mday); printf("month:%d\n",ptr->tm_mon+1); printf("year:%d\n",ptr->tm_year+1900); return 0; }tim 是一个时间计数,是从1900年0分0秒到现在的时间。
所以转化从我们日常用的表示一般年要加上1900,月要加上1,而你这里for (i = 1; day >= days_in_month(i); i++) 表示月的i是从1开始的,tm_mon不是从0开始,所以day也要+1. 因为日常表示中没有0月0号,只有1月1号
stm32rtc实时时钟实验怎么样获取当前时间
展开全部 RTC支持三种中断,分别是秒中断,闹钟中断和溢出中断。
从这三种方式可以看出,正常情况下,RTC的中断是秒级的。
如果使用设置分频的方式让秒中断变成毫秒级中断的话,RTC就不能当作时真正的秒时钟来用了。
如果需要毫秒级中断,推荐使用systick.所有使用Cortex-M3内核的CPU都有一个systick计数器。
在不使用操作系统的工程中,一般都用systick作为毫秒级中断发生器。
在使用ucos或其它简单操作系统的工程中,systick都作为操作系统的系统时钟滴答,周期是1毫秒一个中断。
另外您也可以使用STM32的几个TIM。
TIM1是最复杂的,在只需要简单功能情况下,建议使用TIM2或其它TIM。
...
谁能解释一下STM32F0的RTC
不是的,两个函数的功能是不一样的,可以参考"stm32f10x_rtc.c"展开全部/** * @brief Waits until last write operation on RTC registers has finished. * @note This function must be called before any write to RTC registers. * @param None * @retval None */void RTC_WaitForLastTask(void){ /* Loop until RTOFF flag is set */ while ((RTC->CRL & RTC_FLAG_RTOFF) == (uint16_t)RESET) { }}/** * @brief Waits until the RTC registers (RTC_CNT, RTC_ALR and RTC_PRL) * are synchronized with RTC APB clock. * @note This function must be called before any read operation after an APB reset * or an APB clock stop. * @param None * @retval None */void RTC_WaitForSynchro(void){ /* Clear RSF flag */ RTC->CRL &= (uint16_t)~RTC_FLAG_RSF; /* Loop until RSF flag is set */ while ((RTC->CRL & RTC_FLAG_RSF) == (uint16_t)RESET) { }}...
