素材
机器人眼睛
【推荐学习:css视频教程、jQuery视频教程、web前端视频】
页面布局
机器人样式参考了下图,通过css拼造型的方式进行实现。部分还原了设计图
- 头顶部分 头顶部分是一个圆+伪类after实现白点
<div class="tianxian"></div> .tianxian{ width: 35px; height: 35px; border-radius: 50%; background: #0e58cc; position: absolute; left: 0; right: 0; top: 0; margin: auto; } .tianxian::after{ content: ''; display: block; width: 5px; height: 10px; border-radius: 12px; background: #fff; position: absolute; top: 10px; left: 5px; transform: rotateZ(20deg); }
整体布局采用绝对定位布局 利用整个头部,实现耳朵和眼睛的定位
<div class="head"> <div class="erduo"></div> <div class="erduo"></div> <div class="face"> <div class="eye"></div> <div class="eye"></div> </div> </div>
- 立体效果 通过box-shadow 的inset特性,通过适当偏移x,y轴,实现内阴影的立体效果
box-shadow: -5px -5px 30px 1px #0075af inset;
- 文字转语音实现
基于浏览器提供的SpeechSynthesisUtterance
Api进行实现
SpeechSynthesisUtterance基本属性
SpeechSynthesisUtterance.lang
获取并设置话语的语言SpeechSynthesisUtterance.pitch
获取并设置话语的音调(值越大越尖锐,越低越低沉)SpeechSynthesisUtterance.rate
获取并设置说话的速度(值越大语速越快,越小语速越慢)SpeechSynthesisUtterance.text
获取并设置说话时的文本SpeechSynthesisUtterance.voice
获取并设置说话的声音SpeechSynthesisUtterance.volume
获取并设置说话的音量
SpeechSynthesisUtterance.text基本方法
speak()
将对应的实例添加到语音队列中cancel()
删除队列中所有的语音.如果正在播放,则直接停止pause()
暂停语音resume()
恢复暂停的语音
为按钮添加点击事件,获取input输入框的值,并进行播放,添加眼睛动画,并在播放结束的回调移除眼睛动画
$('#btn').click(function () { let text = $('#input').val() if (text) { $('.eye').addClass('shine') } let u = new window.SpeechSynthesisUtterance() u.text = text u.lang = 'zh' u.rate = 0.7 u.onend = function () { $('.eye').removeClass('shine') } speechSynthesis.speak(u) })
动画类:
.shine { animation: shine 1s linear infinite; } @keyframes shine { 0%{ height: 100px; } 100%{ height: 0px; } }
完整代码:
HTML+CSS
<style> * { margin: 0; padding: 0; list-style: none; box-sizing: border-box; } html, body { width: 100%; height: 100%; overflow: hidden; background: #000; } .robot{ width: 658px; height:800px; position: absolute; left: 0; right: 0; margin: auto; top: 0; bottom: 0; } .tianxian{ width: 35px; height: 35px; border-radius: 50%; background: #0e58cc; position: absolute; left: 0; right: 0; top: 0; margin: auto; } .tianxian::after{ content: ''; display: block; width: 5px; height: 10px; border-radius: 12px; background: #fff; position: absolute; top: 10px; left: 5px; transform: rotateZ(20deg); } .gun{ width: 5px; height: 30px; background:#0075af ; position: absolute; left: 0; right: 0; top: 35px; margin: auto; } .gai{ width: 60px; height: 60px; background: #fff; box-shadow: -5px -5px 30px 1px #0075af inset; position: absolute; left: 0; right: 0; top: 65px; margin: auto; border-radius: 50%; } .head{ width: 370px; height: 350px; position: absolute; left: 0; right: 0; top: 95px; margin: auto; border-radius: 70px; background: #fff; box-shadow: -5px -5px 30px 1px #0075af inset; } .erduo{ width: 60px; height: 180px; background: #0022b0; position: absolute; top: 0; bottom: 0; margin: auto 0; border-radius: 60px; border-top: 4px solid #0e9df9; border-bottom: 4px solid #0e9df9; box-shadow: -5px -5px 30px 1px #0075af inset; } .erduo:nth-child(1) { border-left: 4px solid #0e9df9; left: -40px; } .erduo:nth-child(2){ border-right: 4px solid #0e9df9; right: -40px; box-shadow: -5px -5px 30px 1px #0075af inset; } .face{ width: 288px; height: 244px; background: #03192f; position: absolute; left: 0; right: 0; top: 0; bottom: 0; margin: auto; border-radius: 60px; box-shadow: -5px -5px 30px 1px #0075af inset; } .eye{ width: 30px; height: 100px; background-image: url('https://p6-juejin.byteimg.com/tos-cn-i-k3u1fbpfcp/41c21816e3c740eaa43ade57de3eb5a5~tplv-k3u1fbpfcp-watermark.image'); background-size: contain; position: absolute; top: 0; bottom: 0; margin: auto; } .eye:nth-child(1){ left: 60px; } .eye:nth-child(2){ right: 60px; } .trans{ width:370px; position: absolute; display: flex; justify-content: center; align-items: center; color: #fff; left: 0; right: 0; margin: auto; top: 600px; font-size: 16px; } #input{ margin-right: 10px; background: transparent; border: none; outline: none; color: #fff; border-bottom: 1px dashed #fff; height: 40px; } #btn{ cursor: pointer; } .shine { animation: shine 1s linear infinite; } @keyframes shine { 0%{ height: 100px; } 100%{ height: 0px; } } </style> <body> <div class="robot"> <div class="tianxian"></div> <div class="gun"></div> <div class="gai"></div> <div class="head"> <div class="erduo"></div> <div class="erduo"></div> <div class="face"> <div class="eye"></div> <div class="eye"></div> </div> </div> </div> <div class="trans"> <input id="input" type="text"> <div id="btn">点击朗读</div> </div> </body>
js
$(function () { $('#btn').click(function () { let text = $('#input').val() if (text) { $('.eye').addClass('shine') } let u = new window.SpeechSynthesisUtterance() u.text = text u.lang = 'zh' u.rate = 0.7 u.onend = function () { $('.eye').removeClass('shine') } speechSynthesis.speak(u) }) })
更多编程相关知识,请访问:编程教学!!
以上就是带你使用CSS+jQuery实现一个文字转语音机器人的详细内容,更多请关注其它相关文章!
